Course Overview
This course provides a comprehensive understanding of Instrumentation Engineering practices in industrial projects, covering estimation, design basis, detailed engineering, control systems, and documentation. It is designed for engineers and professionals aiming to enhance their practical knowledge and project execution skills.
Course Modules
1. Project Estimation and Costing
Fundamentals of budgeting, cost estimation, and resource planning.
2. Instrument Design Basis
Setting up the fundamental requirements for instrumentation aligned with project needs.
3. Basic Engineering Package
Design Basis for Plant/Project
Introduction to PFD, P&ID, and PDS
Preparation of Equipment List, Line List, and Equipment Data Sheets
Process Block Diagrams
ISA Codes and Standards Overview
PFD Development and Specification
Basic Process Measurements and Control Fundamentals
4. Process Instrumentation – Selection & Sizing
Flow, Temperature, Pressure, Level Instruments
Transmitters: Selection and Sizing
5. Control Valves and Accessories
Operation Theory
Types of Control Valves
Selection and Sizing of Control Valves
6. Fire and Gas Systems
Operation Principles
Types and Working Principles of Detectors
Selection, Sizing, and Standards for Input/Output Measurements
7. Analysers
Principles of pH, Conductivity, Oxygen
8. DCS and PLC Specifications
Fundamentals and detailed requirements for DCS and PLC system design.
9. Hazardous Area Classification
Zone/Division Classification Methods
Protection Techniques for Hazardous Areas
Hazardous Source List Preparation
Certification Procedures for Hazardous Equipment
Equipment Nameplate Marking
Hazardous Area Layout Drawing Preparation
10. Bill of Materials (BOM) Preparation
Material Identification and Quantity Take-offs
11. Tender Documentation
Preparing project tender documents with technical specifications.
12. Vendor Package Documentation Review
Reviewing and validating vendor-supplied drawings and documentation.
13. Instrumentation Design – Documentation Development
Instrument Index and Plant Location Details
Process and Instrument Data Sheets
Wiring Layouts and Air Routing Diagrams
Logic Diagrams and Loop Drawings
Loop Wiring and I/O List Preparation for DCS Systems
JB (Junction Box) Layouts and Cable Schedules
Cable Tray Layouts and Hook-Up Drawings
14. Assignments
Practical assignments to develop technical skills and reinforce learning.
